JIS Standard Flange Nominal Diameter 10A Stainless Steel Blind 5K BLRF Flange

1.0 Pieces
MOQ
JIS Standard Flange Nominal Diameter 10A Stainless Steel Blind 5K BLRF Flange
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: BLRF
Standard: JIS
Standard Or Nonstandard: Standard
Outside Diamter: 17.3mm
Thickness: 9mm
Bolt Diameter: 12mm
Number Of Bolts: 4
Weight: 0.28kg
Basic Infomation
Model Number: BLRF
Payment & Shipping Terms
Packaging Details: No Fumigate or Fumigate Playwood/Wood Pallet or Box for JIS Standard Flange Nominal Diameter 50mm Stainless Steel
Supply Ability: 450 Metric Ton/Metric Tons per Month
Product Description

JIS Standard Flange Nominal Diameter 50mm Stainless Steel Blind 10K Flange


Product Description
ANSI Stainless Steel Forged Flange
Best quality and competitive price
Description Stainless steel Flange
Products category SOP SOH BL WN MSS API AWWA LONGWN Flange
Airtight surface type
Standard ANSI,DIN,EN,AS,JIS
and customers' drawings for special use
Technology forged Flange
certificate ISO9001:2000,QS-9000,CNAS, TUV, BV
accessories and access to quality inspection
Inspections Factory in-house or Third Party inpection
Our main markets Europe, Middle East Asia,Korea,etc
Material 316L, 316, 304L, 304,
Class 150#,300#,400#,600#,900#,1500#,2500#
Production process raw material--cutting--heating--forging--heat treatment
--maching--inspection.
Application Petroleum, chemical, power, gas, metallurgy,
shipbuilding,construction, etc
Type SLIP-ON SOCKET-WELDING Flange
Delivery 7-45 Days
Remarks As customers' request

1) ANSI B16.5, ASME B16.47 FLANGE

Size range: 1/2" to 24" DN15 to DN600

Design: welding neck, slip on, blind, socket welding, threaded, lap-joint

Pressure: 150#, 300#, 600#,900#,1500#, 2500#

Wall thickness for welding neck flange: STD, SCH40, SCH80, SCH160. SCHXXS

Material: stainless steel 304/304L, 316/316L

Coating: Bright

Package: seaworthy plywooden case, wooden pallet

2) EN1092-1 FLANGE

Size range: DN15 to DN600

Design: type01 plate flange, type02 loose flange, type05 blind flange, type11 welding necking

type12 slip on flange, type 13 threaded flange

Pressure: PN6, PN10, PN16, PN25, PN40, PN64, PN100

Material: carbon steel C22.8, S235, S235JR, P235GH, stainless steel: 304/304L, 316/316L

Coating: Bright

Package: sea worthy plywooden case, wooden pallet

3) DIN FLANGE

Size range: DN15 to DN600

Design: slip on flange DIN2573,2576,2502,2503, 2543,2545

welding neck falnge DIN2631, 2632,2633,2634,2635

blind flange DIN 2527 PN6, PN10, PN16, PN25, PN40

threaded falnge DIN2565,2566,2567,2567

loose flange DIN 2641,2642,2656,2673

Material: stainless steel 1.4301, 1.4404

Coating: rust-proof oil, transparent paint, cold and hot galvanize

Package: sea worthy plywooden case, wooden pallet

4) GOST FLANGE

Size range: DN15 to DN 2000

Design : plate falnge 12820-80, welding neck flange 12821-80

Pressure: PN6, PN10, PN16, PN25, PN40

Material: stainless steel 304/304L, 316/316L

Coating: rust-proof oil, cold and hot galvanize

Package: sea worthy plywooden case, wooden pallet

5) JIS FALNGE

Size ragne : 15A to 2000A

Design: SOP, BIND, SOH,

Puressure: 1K, 2K, 5K, 10K, 16K, 20K, 30K, 40K, 210k, 280k, 350k

Material: stainless steel SUS304, SUS316

Coating : bright

Packing: sea worthy plywooden case, wooden pallet

Production Procedure

Cutting - Heating - Forging - Rough Machinery - Precise Machinery -Drilling - Marking - Cleaning - Packing - Quality Check

Detection Facilities

Company Introduction

Nantong Industrial Products Co., Ltd specializes in sales of

  • Flanges
  • Pipe Fittings
  • Copper Alloy Tubes
  • Casters, Wire Ropes
  • Chain, Slings
  • Ship Accessory
  • Safety Harness and etc.
